Separating two different blocks with SVG shapes creates a more interesting visual appearance than standard horizontal separation.
HTML CODE:
<div class="shape-separator">
</div>
CSS CODE:
.shape-separator {
position: relative;
height: 48px;
background: #333;
}
.shape-separator::after {
content: '';
position: absolute;
width: 100%;
height: 24px;
bottom: 0;
}
Description
- position: relative A Cartesian positioning context is established on the element for the pseudo element.
- ::after Define pseudo elements.
- background-image: url(...) Add a SVG shape (24 x 24 in the base64 format) to the background image of the pseudo-element, which is repeated by default. It must be the same color as the block to be separated.
- position: absolute Takes a pseudo-element from the document stream and positions it relative to the parent element.
- width: 100% Make sure the element stretches the entire width of its parent element.
- height: 24px Same height as shape.
- bottom: 0 Position the pseudo-element at the bottom of the parent element.
